RTD Multiconductor Wire
A thermocouple consists of two wires of dissimilar metals welded together into a junction. At the other end of the signal wires, usually as part of the input instrument, is another junction called the reference junction. Heating the sensing junction generates a thermoelectric potential (emf) proportional to the temperature difference between the two junctions.
| Part Number | No. of Conductors | B & S Gauge | Inner Insulation | Outer Insulation | Maximum Temperature | Nom. Overall Size | |
|---|---|---|---|---|---|---|---|
| °F | °C | ||||||
| LDW-126-101 | 2 | 24 Str. NPC* | Fiberglass 1xRed, 1xWhite | Fiberglass | 900 | 480 | .080″ |
| LDW-120-101 | 3 | 24 Str. SPC** | TFE Teflon® 2xWhite, 1xRed | FEP Jacket White w/SS Overbraid | 392 | 200 | .140″ |
| LDW-120-102 | 3 | 24 Str. SPC** | TFE Teflon® 2xWhite, 1xRed | FEP Jacket, White | 392 | 200 | .125″ |
| LDW-120-103 | 3 | 24 Str. NPC* | Fiberglass 2xRed, 1xWhite | SS Overbraid | 900 | 480 | .115″ |
| LDW-120-104 | 3 | 24 Str. NPC* | Fiberglass 2xRed, 1xWhite | Fiberglass | 900 | 480 | .086″ |
| LDW-122-101 | 4 | 26 Str. SPC** | TFE Teflon® 2xRed, 2xBlack | FEP Jacket, Black | 392 | 200 | .125″ |
* NPC denotes nickel-plated copper
** SPC denotes silver-plated copper
