Cast Bronze Nozzle Heater Bushings
The bronze casting is protected by a stainless steel tube. The maximum operating temperature for the bronze casting is 1200°F (650°C); the optional aluminum casting has a maximum operating temperature of 600°F (315°C). The heater and thermocouple have a standard termination of 36” inch fiberglass leads with a stainless steel overbraid. Options include Teflon® insulated leads and armor cable. All terminations are available with the optional 2-inch-long extended strain relief
Design Features:
- Bronze Cast construction for excellent heat transfer and long life
- Operating Temperature to 1200°F (650°C)
- Built-in Type J or K Thermocouple for accurate temperature control
- Distributed wattage for even heat transfer
- Precision machining of the inside diameter
- Choice of leads and lead protection
Typical Applications:
- Hot Runner Systems
- Sprue Bushings
- Hot Melt Adhesive Systems
- Plastic Injection Nozzles
- Medical, Laboratory and Pharmaceutical Equipment
